型号 |
频率(GHz) |
频率(GHz) |
中心频率 |
带宽 |
隔离度 |
插入损耗 |
驻波比 |
功率 |
IMD |
|
---|---|---|---|---|---|---|---|---|---|---|
HYG842AF[12.7-13.3GHz] | 4.400 | 5.000 | 4.7000 | 0.600 | 23 | 0.30 | 1.15 | 10 | - | |
HYG842AF[10.7-11.7GHz] | 3.400 | 3.800 | 3.6000 | 0.400 | 23 | 0.30 | 1.15 | 10 | - | |
HYG842AF[7.7-8.5GHz] | 3.400 | 3.600 | 3.5000 | 0.200 | 23 | 0.30 | 1.15 | 10 | - | |
HYG842AF[7.1-7.9GHz] | 2.486 | 2.700 | 2.5930 | 0.214 | 23 | 0.30 | 1.15 | 10 | - | |
HYG842AF[6.4-7.2GHz] | 2.545 | 2.665 | 2.6050 | 0.120 | 23 | 0.30 | 1.15 | 10 | - | |
HYG842AF[5.6-6.5GHz] | 2.545 | 2.665 | 2.6050 | 0.120 | 23 | 0.30 | 1.15 | 10 | - | |
HYG842AF[4.4-5.0GHz] | 2.300 | 2.400 | 2.3500 | 0.100 | 23 | 0.30 | 1.15 | 10 | - | |
HYG842AF[3.6-4.2GHz] | 3.600 | 4.200 | 3.9000 | 0.600 | 23 | 0.30 | 1.15 | 10 | - |
