Model |
Frequency(GHz) |
Frequency(GHz) |
Center Frequency |
Bandwidth |
Isolation |
INS LOSS |
VSWR |
Power |
IMD |
|
---|---|---|---|---|---|---|---|---|---|---|
H531K[10.1-10.6]GHz | 10.100 | 10.600 | 10.350 | 0.500 | 22 | 0.4 | 1.2 | 20 | - | |
H531K[9.2-9.8]GHz | 9.200 | 9.800 | 9.500 | 0.600 | 21 | 0.4 | 1.2 | 60 | - | |
H531K[7.1-7.5]GHz | 7.100 | 7.500 | 7.300 | 0.400 | 22 | 0.4 | 1.2 | 10 | - | |
H531K[5.15-5.9]GHz | 5.150 | 5.900 | 5.5250 | 0.750 | 20 | 0.35 | 1.25 | 50 | - | |
H531K[4.4-5]GHz | 4.400 | 5.000 | 4.7000 | 0.600 | 20 | 0.35 | 1.25 | 50 | - | |
H531K[3.7-4.13]GHz | 3.700 | 4.130 | 3.9150 | 0.430 | 20 | 0.35 | 1.25 | 50 | - | |
H531K[3.6-4.2]GHz | 3.600 | 4.200 | 3.9000 | 0.600 | 20 | 0.35 | 1.25 | 50 | - |
